HO Series

Application
STK-HO

STK-HO current sensor is based on the hall open loop principle. DC, AC, pulses and any kind of irregular wave can be measured by the current sensor under the isolated conditions. Product performance:

-open-loop design -current range: ±60,±120,±128,±150 -Frequency bandwidth: 200kHz -Response time: 2μs -Higher isolation voltage
Typical applications:
-AC Variable speed drives -UPS -Power supplies for welding applications -Maximum power point tracker (MPPT)) -Switching mode power supply (SMPS) -Static converters for DC motor drives
Application
STK-HO/1

STK-HO/1 current sensor is based on the open loop principle. DC, AC, pulses and any kind of irregular wave can be measured by the current sensor under the isolated conditions. Product performance:

-open-loop design -current range: ±100,±200 -Frequency bandwidth: 200kHz -Response time: 2μs -Higher isolation voltage
Typical applications:
-AC Variable speed drives -UPS -Power supplies for welding applications -Maximum power point tracker (MPPT)) -Switching mode power supply (SMPS) -Static converters for DC motor drives -Battery supplied applications -Combiner box
Application
STK-HO/2

The STK-HO/2 current sensor is based on the open-loop principle. Under isolation conditions, current sensors can measure DC, AC, pulses, and any type of irregular wave. Product performance:

-Open-loop design -Current range: ±60,±100,±120,±150,±180,±240,±250 -Frequency bandwidth: 200kHz -Response time: 1.5μs -Higher isolation voltage
Typical applications:
-AC Variable speed drives -UPS -Power supplies for welding applications -Maximum power point tracker (MPPT)) -Switching mode power supply (SMPS) -Static converters for DC motor drives -Battery supplied applications -Combiner box
Application
STK-HO/4

The STK-HO/4 current sensor is based on the open-loop principle. Under isolation conditions, current sensors can measure DC, AC, pulses, and any type of irregular wave. Product performance:

-Open-loop design -Current range: ±50,±100,±150,±200,±240,±250 -Frequency bandwidth: 200kHz -Response time: 1.5μs -Higher isolation voltage
Typical applications:
-AC Variable speed drives -UPS -Power supplies for welding applications -Maximum power point tracker (MPPT)) -Switching mode power supply (SMPS) -Static converters for DC motor drives -Battery supplied applications -Combiner box
Application
STK-HO/B

The STK-HO/B series is based on TMR (Tunnel Reluctance) technology and open-loop design, suitable for measuring DC, AC, pulse, and any irregular current under isolated conditions. The nominal current range of the STK-HO/B current sensor consists of 50 A, 75 A, 100 A, 130A, and 180A. Product performance:

-Open loop design -Response time is 0.2 μs -Bandwidth of 1 MHz -TMR sensing technology -Higher isolation voltage
Typical applications:
-AC variable frequency and servo motor drive -Static converters for DC motor drivers -Battery powered applications -Uninterruptible Power Supply (UPS) -Switching Mode Power Supply (SMPS) -Combiner box -Solar inverter (Maximum power point tracker(MPPT)) on the DC side of the inverter -Plasma cutting machine, welding -Charging station
Application
STK-HO/P

STK-HO-P & TP current sensor are based on the open loop principle. DC, AC, pulses and any kind of irregular wave can be measured by the current sensor under the isolated conditions. Product performance:

-Open loop design -Current range: ±50,±100,±150,±200,±240,±250 -Response time is 5 μs -Bandwidth of 50 kHz -TMR sensing technology -Higher isolation voltage
Typical applications:
-AC Variable speed drives -UPS -Power supplies for welding applications -Static converters for DC motor drives -Switched model power supplies (SMPS) -Battery supplied applications -C
